DRS110-111 Modis

PRODUCT INFORMATION

TYPE

• Product type:
  DRS110, 111

FUNCTIONALITY

• Initial LED luminaire efficacy:
  95lm/W
• Color Rendering Index (CRI):
  90 as a standard, 80 on request
• Power supply:
  Philips or Tridonic Driver included
• Light source:
  Philips SLM G7 Premium white

ELECTRICAL PARAMETERS

• Driver efficiency nominal:
  92%
• Electrical isolation class IEC:
  Class II
• Input Frequency:
  50-60 HZ
• Power factor nominal:
  0,95
• Input voltage:
  220 – 240 V
• Power consumption:
  27W, 42W Depends on type

MECHANICAL PARAMETERS

• Ingress protection:
  IP20
• Impact resistance:
  IK02
• Reflector material:
  Faceted anodized aluminum
• Body material:
  Aluminium
• Color:
  White or Black
• Beam angle:
  24, 36,50, 60 dgr
• Installation:
  Recessed

OVERTIME PERFORMANCE

• Driver service life time @10% failures:
  50 000 hours
• Initial system efficacy:
  90 Lm/W
• Luminous flux system tolerance:
  5%
• Median useful life of LED source:
  L80B50, 50 000 Hours
• Power consumption tolerance:
  +/- 10%

ENVIROMENTAL CONDITIONS

• Ambient temperature range:
  0 to +35 °C

GENERAL INFORMATION

• Flammability:
  NO
• Warranty period:
  5 years
• CE mark:
  CE mark
• ROHS mark:
  ROHS compliant
• Application:
  • Shops
  • Show rooms
  • Meeting rooms
  • Circulation areas
  • Hospitality
