URBAN LIGHTING

ROUND URBAN LIGHT

BENEFITS:

DOWNLOADS:

Recommendations PDF

Mounting instructions PDF

PRODUCT FAMILY INFORMATION

TYPE

Product type:

DPS 255

ELECTRICAL PARAMETERS

Driver efficiency nominal:

up to 0.92

Driver failure ratio:

< 10% at 50000 or 100000 hours depends on type

Driver type:

Built in PHILIPS Xitanium Outdoor driver

Electrical isolation class IEC:

Safety class I as a standard, II on request

Input Frequency:

50-60 Hz

LED current ripple %:

< (4-30) depends on type

Mains voltage index:

230 – 240 V / 50 – 60 Hz

Nominal input voltage range:

202..254 or 198…264, depends on type

Power factor nominal:

up to 0.98

Power range:

40 – 60 W depending on type

Surge protection:

4/6 kV

LIGHTING PERFORMANCE

CCT:

3000K, 4000K, 5700K

Color rendering index, CRI:

> 70

Initial color shift, SDCM:

< 5

Light distribution:

Wide beam as standard.

Light source:

Brilux

LOR:

up to 0,89

Luminaire lumen output range, lm:

4200 – 6300 lm depending on type

Photobiological safety:

RG1

Type of optic:

Low ageing PMMA lenses by LEDIL

CONSTRUCTION AND MATERIALS

Dimensions LxWxH:

445×590

Effective protected area:

Housing colour:

Graphite Grey RAL7024

Housing material:

Housing: high-pressure, die-cast aluminium powder coated, no plastic parts

Impact resistance:

IK09

Ingress protection:

IP66

Installation options:

Post top installation 60-76mm

Optical cover:

Extra clear toughened flat glass

Windage area:

no more 0,018sq.m above/below and 0,012sq.m side position

OPERATION AND MAINTENANCE

Electrical connection:

0.4m cable with IP66 connector as standard

Maintenance:

Opening with screw, Opening with screw, LED modules are non-replaceable and can be replaced by manufacturer only

Maintenance of lumen output:

100000 hours – L90B10

Operating temperature range:

-40…+35 C, typical for exact values

Application:

• Parks
• Squares
• Boulevards
• Embankments
• Recreation areas

MARKING AND APPROVALS

CE mark:

CE marked

ROHS mark:

ROHS complaint

CONTACT US FOR MORE INFORMATION
