SPOTLIGHTING

DRS110-111 Modis

BENEFITS:

  • LED accent-lighting solution with a reasonable payback compared to conventional technologies
  • Suitable for food and fashion retailers
  • Available in a choice of black or white finish

DOWNLOADS:

Photometric LDT

Mounting instructions PDF

PRODUCT FAMILY INFORMATION

TYPE

Product type:

DRS110, 111

FUNCTIONALITY

Driver:

Philips or Tridonic Driver included

Initial LED luminaire efficacy:

95lm/W

Optical cover:

Light Color:

3000K, 4000K as a standard, 3500K, 5000K on request

Color Rendering Index (CRI):

90 as a standard, 80 on request

Light Output Range, Lm:

2500-3800 lm (CRI90) as a standard, 3300-4700 lm (CRI80) on request

Optical types:

Lenses DRS110, Aluminium faceted reflector DRS111

Power supply:

Philips or Tridonic Driver included

Light source:

Philips SLM G7 Premium white

ELECTRICAL PARAMETERS

Driver efficiency nominal:

92%

Electrical isolation class IEC:

Class II

Input Frequency:

50-60 HZ

Power factor nominal:

0,95

Input voltage:

220 – 240 V

Power consumption:

27W, 36W Depends on type

MECHANICAL PARAMETERS

Ingress protection:

IP20

Impact resistance:

IK02

Reflector material:

Faceted anodized aluminum

Body material:

Aluminium

Color:

White or Black

Beam angle:

24, 36,50, 60 dgr

Installation:

Recessed

Net weight piece:

OVERTIME PERFORMANCE

Driver service life time @10% failures:

50 000 hours

Initial system efficacy:

90 Lm/W

Luminous flux system tolerance:

5%

Median useful life of LED source:

L80B50, 50 000 Hours

Power consumption tolerance:

+/- 10%

ENVIROMENTAL CONDITIONS

Ambient temperature range:

0 to +35 °C

Average ambient temperature:

GENERAL INFORMATION

Flammability:

NO

Warranty period:

5 years

CE mark:

CE mark

ROHS mark:

ROHS compliant

Application:

• Shops
• Show rooms
• Meeting rooms
• Circulation areas
• Hospitality
