DWL-L







The weather-proof surface-mounted LED luminaires with firmly closing PMMA diffuser are ideal for damp rooms, canopied outdoor areas, swimming pools, in moisture rooms such as canteens or sanitary areas, two things are essential: The new system must be economical and reliable. Above all, energy-efficient LED solutions that save costs and guarantee safe operation with a robust construction are particularly suitable for this.
BENEFITS:
-
-
-
- Up to 50% energy savings compared with TL-D
- Reliable LED technology – maintenance-free
- Direct replacement for conventional waterproof and wall mounted luminaires in terms of light performance
- Universal solution covering various application requirements
-
-
DOWNLOADS:
PRODUCT INFORMATION
TYPE
Product type:
DWL-L
FUNCTIONALITY
Initial LED luminaire efficacy:
120-173 lm/W depends on the type
Color Rendering Index (CRI):
> 80
Power supply:
Driver Philips or Tridonic included
Light source:
LED module with Osram LED chips
Color temperature:
4000K as a standard, 3000,5000,6500K on request
Managing options:
DALI, 1-10V, Motion sensor, wireless connections.
Emergency battery operated hours:
Philips TrustSight system 3 hours light (Basic or self test)
Color tolerance (initial McAdam)
3
ELECTRICAL PARAMETERS
Driver efficiency nominal:
Electrical isolation class IEC:
Class I or Class II on request
Power factor nominal:
0,93
Input voltage:
220 – 240 V
Power consumption:
33-68 W depending on type
MECHANICAL PARAMETERS
Ingress protection:
IP54
Impact resistance:
05
OVERTIME PERFORMANCE
Median useful life of LED source:
L80B20 - 50 000 hours
GENERAL INFORMATION
Dimensions:
Description | L, mm | H, mm | B, mm | E, mm |
DWL-L_120 | 1260 | 105 | 95 | 740 |
DWL-L_150 | 1560 | 105 | 95 | 850 |
Warranty period:
5 years
Pcs on the pallet:
80
Application:
• Parking garages
• Basements
• Cellars
• Warehouses
• General lighting
